Tender Sale of Waldrich-Coburg PMC 3000 AT gantry milling and turning machine
Tender Sale of Waldrich-Coburg PMC 3000 AT gantry milling and turning machine
Manufacturing year 1994
Travels:
X axis (Table1) 7500 mm
X axis (Table2) 7500 mm
X axis (Coupled) 15000 mm
Y axis 1850+3675 mm
Z axis 1250 mm
W axis 2250 mm
Main spindle:
Spindle taper ISO60
DIN 69871
Max power 80 kW
Spindel speed 4000 RPM
Total max load 130000 kg
CNC Control Siemens Sinumerik 880 M
Location: Järvikatu 2-4, 65100 Vaasa
Viewing strictly by appointment.
Available for purchase
Set up
Table width 2000 mm
Setup length of 1st table 6500 mm
Setup length of 2nd table 6500 mm
Total setup length 13000 mm
Max load onto front table 65000 kg
Max load onto front rear 65000 kg
Cross section of ram 600x600mm
Rapid traverse:
15000X mm/min
20000Y mm/min
10000Z mm/min5000W mm/min
Automatic tool changer
Type Fibro robot with rack Tool chain
Stations (pcs) 326 297xISO50 + 28xISO60
The general conditions of Troostwijk Auctions are applicable on this Tender sale.
Kontaktinformationen
Für diese Ausschreibung gibt es keine Online-Gebote. Interessenten werden gebeten, ein schriftliches Angebot per E-Mail abzugeben. Das Gebot ist an die nachstehende E-Mail-Adresse zu senden. Für weitere Informationen können Sie uns gerne per E-Mail.
Phone: +31622456596
